How to Install Tile Backer Boards for Tiling: A Step-by-Step Guide

Fixing tiles directly onto bare plasterboard or raw plywood floors often leads to project failure. Standard plasterboard softens when exposed to moisture, while timber boards flex under foot traffic, causing tiles to crack and grout lines to crumble.

Installing rigid tile backer boards creates an exceptionally strong, dimensionally stable, and moisture resistant substrate for ceramic, porcelain, and natural stone tiles. At Elite Tiling Supplies, we provide trade tilers and general builders across the United Kingdom with high performance fibre cement boards and waterproof backer boards. In this guide, we break down the step-by-step process for installing backer boards onto walls and floors.

Step 1: Select the Correct Board Type and Thickness

Choosing the right backer board specification depends on your substrate and whether you are working on walls or floors:

• For Floor Overboarding: Use six millimetre fibre cement board over timber floorboards to eliminate board bounce without raising overall floor height excessively.
• For Masonry and Stud Walls: Use twelve millimetre cement board or waterproof extruded polystyrene boards (such as Marmox or Jackoboard) to support heavy wall tiles in showers and wetrooms.

Step 2: Prepare the Subfloor or Wall Framework

Before fixing any boards, ensure the supporting structure is clean, flat, and structurally sound:

• Floor Preparation: Secure all loose timber floorboards with countersunk screws. Sweep and vacuum dust and debris thoroughly.
• Wall Preparation: Ensure wall studs are spaced at maximum four hundred millimetre centres and aligned straight using a spirit level.

Step 3: Laying Backer Boards on Floors

When overboarding timber floors, backer boards must be installed using a bed of flexible adhesive alongside mechanical fixings:

1. Spread Adhesive Bed: Apply a continuous bed of flexible S1 tile adhesive onto the floor using a six millimetre notched trowel. This fills small voids and prevents hollow spots beneath the board.


2. Stagger the Board Joints: Lay the fibre cement backer boards into the wet adhesive bed, staggering all joint seams in a brickwork pattern. Never align four board corners together.


3. Secure with Screws: Fasten the boards down using specialised backer board screws at two hundred millimetre intervals, keeping fixings fifteen millimetres away from board edges. Drive screw heads flush with the board surface.

Step 4: Fixing Backer Boards to Stud Walls

When mounting backer boards to timber stud framing in wet areas:

1. Position the Boards: Hold twelve millimetre boards horizontally or vertically against the studs, leaving a three millimetre gap at floor level to prevent capillary moisture rise.


2. Mechanical Fastening: Secure the boards using stainless steel backer board screws and stainless steel fixing washers every three hundred millimetres along stud lines. Washers distribute clamping force and prevent screw heads from pulling through the board core.

Step 5: Seal and Tape Board Joints

To create a continuous, reinforced surface ready for tiling, all board joints must be taped and sealed:

• Standard Dry Areas: Apply self-adhesive alkaline resistant fibreglass scrim tape over all board seams, spreading a thin layer of tile adhesive over the tape using a flat trowel.

• Wetroom and Shower Areas: Apply self-adhesive waterproof tanking tape and joint sealant over all board joins and screw fixings to guarantee complete waterproofing before spreading tile adhesive.

Equip Your Site with Quality Substrates

Taking the time to install rigid cement backer boards guarantees that your tiled walls and floors remain structurally sound, flat, and leak free.
